Telos HX6 Digital Hybrid Broadcast Talk Show 6 Line POTS Phone Audio Interface

( 236067458174) )

$1,064.00 (1 available in stock)

Tested/Guaranteed • Latest Firmware • Very Good Cosmetic Condition • Balanced XLR I/O • Livewire Supported • Superior Audio Quality

Used, in near-mint external cosmetic condition. There's signs of prior use on the OLED display but the menus are clear and easy to follow - see photo. The firmware has been updated to the latest version available at the time of listing. I was able to obtain CLI transfer from my OBI202 VoIP ATA (see Xscreen screenshot), but implementations vary so I can't guarantee the same for all VoIP systems that emulate an analog copper twisted pair, the the balance of probability is that you will get the same results. Ships in plain packaging. No printed manual is included, but a copy may be downloaded from https://www.prostudioconnection.net/2404/Telos_Hx6_Hybrid_Manual.pdf . No software, unpictured cables, accessories or documents are included.

Description

The Telos Hx6 is a six-line broadcast phone system equipped with Telos hybrids and a suite of audio processing capabilities, aimed at broadcasters with ‘phone-centric’ programming.

Usually Sells for $3,500

The Hx6 is designed to extract caller audio from far-end connections including POTS and ISDN lines, and is equipped with dual hybrids for high-quality conferencing – the same technology used in the Telos Hx1 and Hx2 telephone hybrids. The unit’s DSP algorithms are optimised for audio performance with a wide variety of incoming call types. DDEQ (Digital Dynamic EQ) and adjustable smart-level AGC, work with symmetrical wide-range AGC from Omnia Audio, to provide consistent audio from call to call.

Telos VSet6 six-line phone controllers with large VGA LCDs provide users with intuitive operation and set-up, with Status Symbols providing animated, high-contrast icons that communicate line and caller status.

Features

Six-line capacity; works with POTS (analog) phone lines.
Our most advanced digital hybrids, with DSP algorithms optimized for superior performance with today’s wide variety of far-end call types (VoIP, cell, POTS, app-based).
Telos DDEQ (Digital Dynamic EQ) and adjustable smart-level AGC ensure spectrally consistent audio from call to call — even on notoriously tough cellular calls.
Excellent trans-hybrid loss of >55dB.
Smooth, proven, symmetrical wide-range AGC by the audio processing experts at Omnia.
Studio adaptation and a subtle, inaudible pitch shifter to prevent feedback in open-speaker studio environments.
A sophisticated caller override that improves performance and allows precision adjustment of the degree to which talent audio “ducks" the caller audio.

https://www.prostudioconnection.net/2504/IMG_0127.JPG

Striking Telos VSet6 six-line phone controllers with large, colorful VGA LCD displays that provide intuitive operation and setup. Telos-exclusive Status Symbols provide producers and talent with animated, high-contrast icons that communicate line and caller status at a glance.
Caller ID displayed on the VSet6 phoneset and the XScreen call-screening application (not included).
Livewire IP-Audio allows fast, one-cable integration with Axia networks, and provides Axia board operators with seamless, on-console control of multiple lines and hybrids. Standard Ethernet backbone provides a common transport path for both studio audio and telecom needs, resulting in cost savings and a simplified studio infrastructure.
Standard Analog I/O.
Easy setup and configuration via Ethernet using any PC and your favorite Web browser.
