Symmetricom TrueTime XL-AK GPS 10Mhz TCXO Oscillator Pulse Generator with TI/ET [Used]

( 236351945494) )

Regular price $495.00 $0.00      (1 available in stock)

Tested/Guaranteed • TCXO Oscillator • 10MHz GPSDO • 5 Frequency/Pulse/Timecode Output BNC Ports • Time Interval/Elapsed Time Option • Test Antenna & Rack Ears Included • 1PPS • IRIG-B

https://www.prostudioconnection.net/2509/C1028783c.jpg

Photos show the actual item for sale

https://www.prostudioconnection.net/2509/C1028791.JPG

A very lightly used XL-AK GPS Disciplined Clock/Frequency/Pulse Generator with a TCXO oscillator installed. The five BNC IRIG/pulse output BNC connectors can be set for a wide range of pulse frequencies via internal jumpers (see photo). The output from the console port obtained during testing is copied below. The photos show the actual item for sale.  A few small nicks and scratches have been retouched so the item will look pristine when installed in your rack. The clock shows the correct time and date and the internal 3.7V Lithium battery for maintaining settings has just been replaced with a fresh cell so you should be good for some years to come. Full product details may be found in the User Manual at https://www.prostudioconnection.net/1311/XL-AK_Manual.pdf. A basic puck antenna is included to allow you to test the unit immediately upon receipt. For a permanent installation and accurate time/frequency generation a professional grade outdoor antenna with a clear view of the sky will be required. I can provide a recommendation if required - the antenna voltage is 5V so almost any professional grade outdoor antenna can be used. The LCD display does have a backlight.

https://www.prostudioconnection.net/2509/Symmetricom%20TrueTime%20XL-AK%20GPS%20Disciplined%2010Mhz%20TCXO%20Oscillator%20Pulse%20Generator-01.PNG

https://www.prostudioconnection.net/2509/C1028781c.jpg

Description

The rack-mount XL-AK GPS receiver provides ultra-precise time and frequency. This configurable instrument provides timing outputs to within 40 nanoseconds rms of UTC/USNO and frequency outputs accurate to less than 1x10-12, even when tracking satellites with Selective Availability (SA) implemented. User-configurable outputs provide significant flexibility in configuring the XL-AK as a central source for IRIG time codes or output pulses.


https://www.prostudioconnection.net/1707/P5222573b.PNG

https://www.prostudioconnection.net/1608/XL-AK_1.png

https://www.prostudioconnection.net/2509/C1028784.JPG

https://www.prostudioconnection.net/2509/C1028786.JPG

https://www.prostudioconnection.net/1608/XL-AK_2.png

https://www.prostudioconnection.net/2509/C1028789.JPG

https://www.prostudioconnection.net/2509/C1028790.JPG

https://www.prostudioconnection.net/2509/C1028782.JPG
https://www.prostudioconnection.net/2509/C1028787.JPG

https://www.prostudioconnection.net/2306/IMG_6489.JPG

https://www.prostudioconnection.net/2509/C1028788.JPG

Console Port Output

269:21:17:56

269:21:17:57

f01

F01 +00:00

f02

F02 24

f03

F03 UTC 09/26/25 21:18:14

f05

F05 ON 00000001000 00000010000 00000100000 00001000000

f07

ERROR 05 NO SUCH FUNCTION

f11

F11

f13

F13 00.000000200

f14

ERROR 05 NO SUCH FUNCTION

f15

F15 OFF

f17

ERROR 05 NO SUCH FUNCTION

f18

TRUETIME XL ACE3 sys ver 030 GPS-XL V1.047 182-6170v006

f26

F26 000:00:00:00.000 000:00:00:00.000

f28

OK

f29

F29 OFF

f50

F50 N 28d32'11.1" W 082d33'2.7" 10m pdop 2.19

f51

F51 +50ns

f52

F52 +0ns

f53

F53 AUTO: 8 SATS

f55

F55 METERS

f56

F56 N 28d32'11.1" W 082d33'2.7" 11m COUNT 1862 / 90000

f60

F60 prn 1 good enabled sig level= +0.00

F60 prn 18 good enabled sig level= +0.00

F60 prn 26 good enabled tracked current sig level= +12.60

F60 prn 29 good enabled sig level= +0.00

F60 prn 5 good enabled sig level= +0.00

F60 prn 20 good enabled sig level= +0.00

F60 prn 22 good enabled sig level= +0.00

F60 prn 2 good enabled sig level= +0.00

F60 prn 21 good enabled sig level= +0.00

F60 prn 31 good enabled tracked current sig level= +14.80

F60 prn 7 good enabled sig level= +0.00

F60 prn 17 good enabled sig level= +0.00

F60 prn 15 good enabled sig level= +0.00

F60 prn 28 good enabled tracked current sig level= +6.20

F60 prn 4 good enabled tracked current sig level= +7.80

F60 prn 25 good enabled sig level= +0.00

F60 prn 9 good enabled sig level= +0.00

F60 prn 19 good enabled sig level= +0.00

F60 prn 24 good enabled sig level= +0.00

F60 prn 27 good enabled tracked current sig level= +7.00

F60 prn 14 good enabled sig level= +0.00

F60 prn 6 good enabled sig level= +0.00

F60 prn 16 good enabled tracked current sig level= +10.60

F60 prn 3 good enabled tracked current sig level= +12.20

F60 prn 10 good enabled sig level= +0.00

F60 prn 8 good enabled sig level= +0.00

F60 prn 11 good enabled sig level= +0.00

F60 prn 13 good enabled sig level= +0.00

F60 prn 12 good enabled sig level= +0.00

F60 prn 30 good enabled sig level= +0.00

F60 prn 23 good enabled sig level= +0.00

F60 prn 32 good enabled tracked current sig level= +7.80

f66

F66 OFF

f68

F68 2025

f69

F69 UTC

f71

F71 phase=-1.205E-08 s offset= 2.125E-12 drift= 2.716E-07/DAY DAC=-13586

f72

F72 Antenna: OK PLL: OK GPS: Locked

f73

F73 SLBA8G--- M-------- m--------
